034Motorsport Dynamic+ Sway Bar Kit (Part Number: 034-402-1035)

The 034Motorsport Dynamic+ Sway Bar Kit is engineered specifically for the B8/B8.5 platform, fitting Audi A4/S4/RS4 and A5/S5/RS5 models from 2008 to 2017. This kit is designed to enhance your vehicle's handling dynamics by reducing body roll and improving steering response, making it an essential upgrade for both street performance and track use.

Construction and Design

This sway bar kit features front and rear sway bars constructed from high-quality spring steel, ensuring maximum rigidity and durability. The front sway bar has a diameter of 28.6mm with a hollow design that includes thicker walls compared to the factory bar. The rear sway bar measures 25.4mm and is a one-piece solid construction, providing consistent performance under load.

Adjustability

Both sway bars are 2-way adjustable, allowing you to fine-tune the handling characteristics of your Audi:

• Front Sway Bar:
  • Soft: +21% increased sway bar rate
  • Stiff: +41% increased sway bar rate
• Rear Sway Bar:
  • Soft: +128% increased sway bar rate
  • Stiff: +156% increased sway bar rate

Performance Benefits

Installing the Dynamic+ Sway Bar Kit enhances your vehicle’s agility and steering precision. The optimized design significantly reduces front body roll, increases front-end responsiveness, and improves overall steering feel. The rear sway bar reduces understeer and enhances turn-in rotation during cornering, providing a balanced and predictable driving experience.

Installation Notes

For a seamless installation process, reference the following guides:

• Front Sway Bar Installation Guide
• Rear Sway Bar Installation Guide

Fitment

• Audi A4 B8/B8.5 2.0 TFSI (2009-2016)
• Audi A4 B8/B8.5 3.2L FSI (2009-2016)
• Audi A5 B8/B8.5 2.0 TFSI (2008-2017)
• Audi A5 B8/B8.5 3.2L FSI (2008-2017)
• Audi Allroad B8/B8.5 3.2 TFSI (2010-2016)
• Audi RS5 B8/B8.5 4.2L FSI (2010-2017)
• Audi S4 B8/B8.5 3.0 TFSI (2010-2017)
• Audi S5 B8/B8.5 3.0 TFSI (2008-2017)
• Audi S5 B8/B8.5 4.2L TFSI (2008-2017)

Important Considerations

This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.

For vehicles that have been lowered, it is crucial to check for clearances throughout the suspension's full range of motion to avoid any potential interference. It is recommended to pair these sway bars with 034Motorsport suspension components, which are designed to work together without clearance issues.
