Brembo 09.A047.3X Premium UV Coated Front Xtra Cross Drilled Brake Rotor

The Brembo 09.A047.3X brake rotor is engineered as a direct replacement component, designed to meet or exceed OEM specifications. This rotor features a UV coating that not only provides superior protection against environmental factors but also enhances the longevity of the braking surfaces. The solvent-free coating is environmentally friendly while ensuring optimal performance in various driving conditions.

Construction and Design

Crafted from high carbon cast iron, the rotor minimizes noise and vibration, contributing to a more comfortable driving experience. The drilled braking surface enhances heat dissipation and improves overall braking performance. This rotor is designed to be paired with Brembo's NAO/Ceramic or Low Met brake pad formulations to optimize braking efficiency.

Specifications

• Braking Surface: Drilled
• Torque Spec (NM): 120
• Minimum Thickness (MM): 20.4
• Centering Diameter (MM): 64.1
• Number of Holes: 4
• Outside Diameter (MM): 294
• Solid or Vented Type Rotor: PVT
• Nominal Thickness (MM): 21.9
• Height (MM): 44.1
• Rust Resistant Coating: UV Coated
• Material: High Carbon

Installation Notes

The Brembo 09.A047.3X rotor comes with a fixing screw kit that includes all necessary hardware for a straightforward installation. For optimal braking performance, it is recommended to replace rotors and pads simultaneously.

Fitment

This rotor is compatible with the following models:

• Mini Cooper (2007-2015)
• Mini Coupe (2012-2015)
