The PRO-HY69.4B is a high-powered, water-resistant hybrid loudspeaker that combines a 6x9" midrange speaker with a high wattage driver to provide a full range of frequencies at an impressively loud volume. The PRO-HY69.4B features a 1" compression driver horn, made with a titanium diaphragm and neodymium magnet, for clear and powerful high-frequency sound. With a maximum power handling of 500 watts and a sensitivity of 97 dB, this speaker is perfect for those who want to place a high wattage, high volume loudspeaker with a powerful driver into their motorcycles to save on space and increase the quality of their sound. The water-resistant cone helps protect the speaker from the elements, making it ideal for outdoor use. The PRO-HY69.4B also has a nominal impedance of 4 ohms, a frequency response range of 50Hz-20KHz, and a recommended hi-pass crossover of 80Hz for improved audio performance and longevity, making it a great choice for a range of audio applications. The PRO-HY69.4B is an excellent choice for anyone seeking a powerful and versatile speaker for their sound system.

Features :

• 6x9" Hybrid Coaxial Mid-Range w/Driver
• RMS Power: 250 Watts(500 Watts Peak)
• Impedance: 4 Ohm
• Ferrite & Neodymium Magnets
• Water Resistant IPX5
• 97dB

Specifications :

• Nominal Diameter : 6x9" / 152 x 228mm
• Nominal Impedance : 4 Ohm
• RMS Power Handling : 250W
• MAX Power Handling : 500W
• Sensitivity (1w/1m) : 97dB
• Frequency Response : 50Hz - 20Khz
• Recommended HI Pass Crossover : 80Hz
• Number of ways : 2 ways
• Pair or Single : Single
• Grill Included : Yes
• Woofer Specifications
• Voice Coil Diameter : 1.5"/ 38.6mm
• Voice Coil Former Material : Glass Fiber
• Winding Material : CCAW
• Cone Material : Water Resistant Paper (IPx5)
• Surround Material : Cloth
• Basket Material : Aluminum
• Basket Color/Finish : Matte Black
• Magnet Material : Ferrite
• Magnet Weight : 27 Oz
• Displacement Volume : 0.051L / 0.0018ft3
• Thiele & Small Parameters
• Equivalent Volume Vas : 14.84L / 0.52ft3
• Excursion (one way) Xmax : 9.2mm
• Free Air Resonance Fs : 87Hz
• Mechanical Factor Qms : 3.629
• Electrical Factor Qes : 0.661
• Total Factor Qts : 0.559
• Mechanical Mass Mms : 14.264g
• Mechanical Compliance Cms : 0.236 mm/N
• BL Factor BL : 6.135
• Voice Coil Inductance Le : 4.22mH
• Cone Area Sd : 210.48 Cm2
• DC Resistance Re : 3.2 ohms
• Mechanical Mass w/o air Mmd : 12.509g
• Driver Specifications
• Voice Coil Diameter : 1" / 25.4mm
• Voice Coil Former Material : Kapton
• Winding Material : CCAW
• Diaphragm Material : Titanium
• Magnet Material : Neodymium
• Horn Diameter : 3.26" / 83mm
• Speaker Measurement
• Overall Diameter : 9.45 X 6.57" / 240 X 167mm
• Overall Depth : 4.54" / 115.4mm
• Front Mount Baffle Cutout : 8.74 X 5.98" / 222 X 152mm
• Mounting Depth : 4.21" / 107 mm
• Motor Diameter : 4.61" / 117mm

Install Instructions :

• For Instructions CLICK HERE
