Eagle Specialty Products B18022060 Balanced Street & Strip Rotating Assembly

The Eagle B18022060 Balanced Street & Strip Rotating Assembly is engineered for performance and durability, making it an excellent choice for building naturally aspirated, pump gas street engines. This assembly is designed to replace original equipment parts without compromising quality, ensuring reliability on both the street and at the strip.

Specifications

This rotating assembly features:

• Crankshaft Stroke: 4.250 inches
• Connecting Rod Length: 6.385 inches
• Piston Bore Diameter: 4.310 inches
• Piston Dome Volume: 18cc
• Piston Material: Forged 4032 aluminum
• Connecting Rod Design: I-Beam, forged 5140 steel
• Crankshaft Material: Cast steel
• Flexplate: 168 tooth included

Assembly Features

• Assembly Balanced: Yes
• Balance Type: External
• Connecting Rod Bolt Diameter: 7/16 inches, ARP 8740 material
• Piston Ring Type: Plasma-moly file-fit for optimal sealing
• Damper: Included

Installation Notes

Minor clearancing of the block may be required during installation. Ensure compatibility with your specific engine setup to maximize performance.
