Name: Eagle Specialty Prod Chvrolet Big Block 2pc Rear Seal Competition Balanced Rotating Assembly
Brand: Eagle
SKU: VR-152672701
Price: 3128.99 USD
Availability: InStock

If you're diving into the world of racing engines, the Eagle Competition Rotating Assembly is a solid pick. These guys really know their stuff when it comes to performance parts. They’ve put together an assembly that balances reliability and durability without sending your wallet into a tailspin. Whether you're running exotic fuels, nitrous, or forced induction, this assembly is built to handle it all.

What are you getting? Well, it starts with a 4.250" forged 4340 crank that’s tough enough to take a beating. Paired with 6.385" H-Beam rods and 7/16" ARP 8740 bolts, you know this setup is solid. The forged 4032 Mahle pistons come with an 18cc dome, and the plasma-moly file-fit rings are there to ensure you’re sealing things up tight. Plus, you’ll get King XP rod and main bearings that are designed for high-performance applications.

Features

Assembly Balanced: yes
Balance Type: internal
Connecting Rod Bolt Diameter: 7/16"
Connecting Rod Bolt Material: ARP 8740
Connecting Rod Design: H-Beam
Connecting Rod Length: 6.385"
Connecting Rod Material: Forged 4340 Steel
Crankshaft Center Counterweights: yes
Crankshaft Flange Bolt Holes: 6
Crankshaft Main Journal Diameter: 2.749"
Crankshaft Material: Forged 4340 Steel
Crankshaft Reluctor: no
Crankshaft Rod Journal Diameter: 2.200"
Crankshaft Stroke: 4.250"
Cylinder Bore Diameter: 4.310"
Damper Included: no
Flexplate/Flywheel Included: no
Main Bearing Type: Hardened, Narrowed or Chamfered
Main Bearings Included: yes
Oil Rail Support Included: yes
Piston Brand: Mahle
Piston Dome Volume: 18cc
Piston Face Type: Dome
Piston Material: Forged 4032 Aluminum
Piston Pin Diameter: .990"
Piston Pin Type: Full Floating
Piston Ring Gap: File Fit
Piston Ring Thickness: 1.5mm, 1.5mm, 3.0mm
Rod Bearing Type: Hardened, Narrowed or Chamfered
Rod Bearings Included: yes
Second Piston Ring Type: Reverse Twist Iron
Thrust Washer Included: no
Title: Eagle Specialty Products - Balanced Competition Rotating Assembly
Top Piston Ring Type: Barrel Faced Plasma-Moly
Heads up: you might need to do some minor clearancing of the block to get everything to fit just right.

Notes:

Universal Fitment: While this assembly is designed to fit a range of setups, it’s always a good idea to do your homework on fitment for your specific application. Make sure it’s the right match for your engine.
