5VX2000 Super HC Molded Notch V-Belt

The 5VX2000 Super HC Molded Notch V-Belt is designed for high-horsepower applications where space is limited. With its unique construction, this belt stands out by transmitting up to three times the horsepower of comparably sized belts, making it an ideal choice for compact and efficient drive systems.

Key Benefits

• Promotes quieter operation with less slippage, leading to reduced wear and extended belt life, which ultimately minimizes maintenance costs.
• Compact design tailored for high horsepower applications, fitting perfectly in small pulley diameter drives.
• Patented Flex-Weave cover protects the belt core from oil, contaminants, and heat, ensuring longevity.
• Flex-bonded cords offer excellent load distribution and resistance to fatigue, absorbing bending stress without deterioration.
• Precision-ground straight sidewalls guarantee a snug fit in pulley grooves, promoting even wear and prolonged lifespan.
• Molded notches optimize thermal and bending stress distribution, reducing operational noise.
• Constructed from a patented Ethylene Elastomeric compound that withstands heat, ozone, and sunlight.
• Meets ARPM/RMA IP-3-2 oil and heat resistance standards and ARPM/RMA IP-3-3 static conductivity requirements.
• Temperature Range: -70°F to +250°F (-57°C to +121°C).

Specifications

• Type: Narrow Section Molded Notch V-Belt
• Section: 5VX
• Number of Strands: 1
• Top Width: 16 mm
• Outside Circumference: 5080 mm
• Construction: Notched
• Belt Material: Ethylene Elastomer (EE)
• Cord Material: Polyester

Available Options

The 5VX2000 is available in various cross-sections including 3VX, 5VX, and 8VX, as well as Super HC Molded Notch PowerBand joined V-belts, catering to a wide range of applications and preferences.

Choose the 5VX2000 Super HC Molded Notch V-Belt for a reliable, efficient, and durable solution to your high-horsepower needs in compact spaces.
