Howards Cams 4.500″ Flat Top Pro Max 2618 Forged Race Pistons (Set of 8) Chevrolet Big Block V8
$1,022.13
Model: 855027303
Description
Howards Cams 4.500″ Flat Top Pro Max 2618 Forged Race Pistons (Set of 8) for Chevrolet Big Block V8
Looking to take your Chevrolet Big Block V8 to the next level? The Howards Cams 4.500″ Flat Top Pro Max 2618 Forged Race Pistons are designed to deliver exceptional performance and reliability on the track. Crafted from high-quality 2618-T61 aluminum, these pistons are engineered for serious racing enthusiasts who demand the best from their engines.
Why Choose Howards Pro Max 2618 Forged Race Pistons?
These pistons are not your average components; they are forged from premium billet aluminum, making them stronger and more durable than standard pistons. With less than 1% silicon content, they can withstand extreme stress and high RPMs without compromising shape or integrity. Say goodbye to issues like “skirt shrinking” that can plague inferior pistons!
Key Features
- Forged from 2618-T61 Billet Aluminum Bar Stock: Ensures durability and strength.
- Oversize Valve Pockets: Accommodates large cam profiles and oversized valves.
- Accumulator Grooves: Improves ring seal for better performance.
- Machined Oil Drain Back Holes: Enhances oil management.
- Lightweight Aircraft Quality Wrist Pins: Included for reduced weight.
- Lock Removal Indents: Makes assembly easier.
- CNC Turned Skirts: Reduces friction and wear.
- Radius Valve Reliefs: Minimizes hot spots.
- 1/16″, 1/16″, 3/16″ Ring Grooves: Standard sizing for compatibility.
- Forced Pin Oilers: Ensures proper lubrication.
- Honed Pin Bores: Provides a precise fit.
- Double Spirolox: Secure pin retention.
Specifications
- Part Type: Pistons
- Model: Pro Max 2618 Forged Race Pistons
- Application: Chevrolet Big Block V8
- Piston Style: Flat Top
- Cylinder Bore: 4.500″
- Compression Distance: 1.270″
- Crankshaft Stroke/Rod Length: 4.250″ with 6.385″ Connecting Rod
- Deck Height (Zero Deck): 9.780″
- Dome Volume: -3cc
- Compression Ratio: 9.3 with 119cc Heads
- Piston Material: Forged 2618-T6 Aluminum
- Accumulator Grooves: Yes
- Forced Pin Oilers: Yes
- Skirt Coating: Yes, CNC Turned Skirts
- Wrist Pin Style: Press-Fit or Floating
- Wrist Pins Included: .150″ Heat Treated Aircraft Quality Steel
- Pin Lock Included: Double Spirolox
- Ring Grove Sizes: 1/16″, 1/16″, 3/16″
- Manufacturer: Howards Cams & Racing Components
- Warranty: Race Application. No warranty expressed or implied.
- Quantity: Sold as Sets of 8
Popular Fitments
- Chevrolet Chevelle SS 454
- Chevrolet Camaro Z28 with Big Block
- Chevrolet Impala with Big Block V8
- Chevrolet Corvette with Big Block V8
Customer Reviews
Users rave about the Howards Pro Max 2618 pistons, praising their durability and performance on the track. One customer noted, “These pistons held up under extreme conditions during racing, and I noticed a significant improvement in power delivery.” Another user mentioned, “Installation was straightforward, and the fit was perfect. Definitely a great investment for serious racers!”
Upgrade your Chevrolet Big Block V8 with Howards Cams 4.500″ Flat Top Pro Max 2618 Forged Race Pistons and experience the difference in performance and reliability!
