Name: Mishimoto Performance Intercooler Chevrolet Camaro | Cadillac ATS 2017-2023
Brand: Mishimoto
SKU: misMMINT-CAM4-16KWBK
Price: 1586 USD
Availability: InStock

Its time to give the intercooling system in your 2016+ Chevrolet Camaro 2.0T or 2013+ Cadillac ATS a complete overhaul with the Mishimoto Performance Intercooler Kit. Our bar-and-plate constructed core picks up the slack for the stock unit by offering increased heat rejection characteristics, as well as a boost in airflow. On top of the new construction, our design increases the internal core volume by 45 percent, and offers a whopping 239 percent gain in external fin surface area, making sure that the charged air running through your LTG is as chilled as possible. Our kit also includes a set of our mandrel-bent intercooler piping featuring a range of 2.25-2.75" diameters equating in a 30 percent increase in volume and 10 percent better flow of the charged air. All together, our piping kit gits your LTG powered Camaro or ATS up to 11 additional horsepower and 9 ft-lbs of torque. We have also included a pre-Welded NPT port on the cold side piping that not only allows for easy installation of your stock equipment, but also adding an aftermarket boost gauge or meth-injection is a breeze. The Mishimoto Performance Intercooler Kit for your 2013+ ATS or 2016+ Camaro is available with your choice of polished or wrinkle black piping, and as always this kit is covered under the Mishimoto Lifetime Warranty.

Purchase Includes:

(1) Aluminum Intercooler
(2) Aluminum Pipes w/ CNC-machined quick-disconnects
(1) Aluminum Pipe w/ CNC-machined 2-bolt flange
(2) Quick-Disconnect Spring Clips
(1) 2.75"0-degree Silicone Coupler
(1) 2.25to 2.5 ilicone Transition Coupler
(1) 2.5 -bolt Clamp
(1) 2.75"-bolt Clamp
(2) 3T-bolt Clamps
(3) Tree Clips
Mishimoto Lifetime Warranty

Features:

10% increase in volume and 40% increase in flow over stock cold-side pipe
14% increase in volume and 26% greater flow than stock hot-side pipe
4.3" thick intercooler design optimized for maximum flow
8 hp/10 tq gains when combined with other Mishimoto Focus ST parts
Cold-side pipe has elliptical shape to accommodate for larger Mishimoto radiator
Direct fit for the 2013-2018 Ford Focus ST
Increases core size by 128% and fin surface area by 32%
Mishimoto Lifetime Warranty
No modification to front bumper and retains stock fog lights
No modification to front bumper and retains stock fog lights
Optimal core design for maximum cooling efficiency with minimal pressure drop
Provision for both US and Euro MAP sensor

Specifications:
