SAE tin-plated brass automotive posts & 3/8 inch threaded SS stud terminals

Today's commercial vehicles have to power a range of accessories, both inside the cab and out. And whether on the land or sea, ODYSSEY batteries have the power to start any job, and the durability to last until It's finished.

Featuring rugged construction and packed tightly with pure lead plates, the non-spillable AGM design ODYSSEY battery protects against the shock and vibration that can quickly destroy other batteries. And the pure lead plates mean 2 times the overall power and 3 times the life of conventional batteries, up to 400 cycles at 80% depth of discharge!

Bottom line? ODYSSEY batteries deliver massive starting power, rapid recovery, and extreme durability that heavy duty and commercial vehicles demand.
Dimensions:

• Length: 11.30 in
• Width: 10.60 in
• Height (terminals included): 9.20 in
• Height (container): 8.20 in
• Weight: 86.0 lbs

Specifications:

• Voltage: 12V
• Pulse (5 second) Hot Cranking Amps (PHCA): 2250A
• Cold Cranking Amps (CCA): 1225A
• HCA: 1730A
• MCA: 1550A
• 20Hr Nominal Capacity (Ah): 126ah
• 10Hr Nominal Capacity (Ah): 114ah
• Reserve Capacity Minutes: 240 mins
• Terminal: SAE and 3/8-16" Stud
• Torque Spec in-lbs (Nm max): 100 (11) stud only
• Internal Resistance (mΩ): 2.5
• Short Circuit (A): 5000A
• Recommended Min. Charging Current (A): 11.4A
• Operating Temperature Range: -40°F / -40°C to 113°F / +45°C
• Optimum Storage Temperature: 68°F / +20°C
• UPC: 635241140866

Specifications Sheet:

• For Instructions CLICK HERE
