Featuring rugged construction and packed tightly with pure lead plates, the non-spillable AGM design ODYSSEY battery protects against the shock and vibration that can quickly destroy other batteries. And the pure lead plates mean 2 times the overall power and 3 times the life of conventional batteries, up to 400 cycles at 80% depth of discharge!

Bottom line? ODYSSEY batteries deliver massive starting power, rapid recovery, and extreme durability that heavy duty and commercial vehicles demand.
Dimensions:

• Length: 10.90 in
• Width: 6.80 in
• Height (terminals included): 8.80 in
• Height (container): 8.20 in
• Weight: 57.10 lbs

Specifications:

• Voltage: 12V
• Pulse (5 second) Hot Cranking Amps (PHCA): 1500A
• Cold Cranking Amps (CCA): 840A
• HCA: 1200A
• MCA: 1000A
• 20Hr Nominal Capacity (Ah): 76ah
• 10Hr Nominal Capacity (Ah): 73ah
• Reserve Capacity Minutes: 160 mins
• Terminal: SAE
• Torque Spec in-lbs (Nm max): N/A
• Internal Resistance (mΩ): 3
• Short Circuit (A): 3100A
• Recommended Min. Charging Current (A): 7.3A
• Operating Temperature Range: -40°F / -40°C to 176°F / +80°C
• Optimum Storage Temperature: 68°F / +20°C
• UPC: 635241141221

Specifications Sheet:

• For Instructions CLICK HERE
