A portal gear lift is the pinnacle of power and performance, and nobody does it better than GDP. So get SuperATV's Polaris RZR 900 4" GDP Portal Gear Lift to take your ride to the next level. You get your choice of 15% or 30% gear reductions and cast or billet aluminum housings. On top of getting your perfect torque, you have the option to upgrade to dual idler gears for ultimate strength.

Perfection takes time. After years of research and development, we've made our dual idler gear portals unlike any other. By placing a second idler gear in the portal box, the load gets spread over twice as much surface area for more reliable torque transfer and the strongest gear set you can get. Two idler gears don't do a thing if they're not mated perfectly, though. Precision CNC grinding ensures ours do. Our gears are made from the industry's toughest 9310 steel alloy. Didn't think dual idlers mattered? With GDP's quality and experience, they finally do.

If you like getting down and dirty, choose a 30% gear reduction and start flingin' mud. It gives you low-end torque for massive tires and power to push through peanut butter mud. If you prefer to drive flat out, choose a 15% gear reduction. It still gives you a bunch of torque for bigger tires but leaves plenty of your top-end speed. No matter where or how you ride, we've got you covered.

These RZR 900 portals put the gear reduction in the hub and makes life easier for the entire drivetrain. Your axles maintain factory geometry and work less. Your axles, prop shaft, differential, and transmission are under less stress. That means longer lasting components, and a lift that doesn't destroy your machine.

We dare you to find something stronger than GDP portals. Just like everything else that goes into this product, our housings are well researched and long tested. Whether you choose cast or billet aluminum, they come paired with our advanced steel alloy backing plates to make your hubs stronger than any alternative.

• Our housings are reinforced for gear retention and optimized for oil flow
• Advanced steel alloy backing plates are stronger than chromoly
• Enhance with Portal Blood-gear oil formulated for GDP Portals
• There are no gimmicks and no vents because vents do more harm than good-we know because we tested them

Advanced Gaskets, Seals, and Bearings

Our portals use:

• Advanced gaskets and O-rings with excellent oil resistance and low deterioration rates
• A sealed input gear and double-lipped output seal
• 100% sealing coverage throughout so you can forget about oil leaks
• Double-angular contact output bearings to prevent premature wear
• Roller idler and drive bearings to maintain perfect gear meshing

Features:

• Available with billet or cast aluminum housing
• Dual idler gear configuration maximizes strength
• Cool, quiet, precision-ground gears made from 9310 alloy billet steel
• 1.5 in. diameter 4340 hardened steel drive shaft
• Housings use advanced gaskets or O-rings that don't let anything through
• Universal hub fits all major bolt patterns
• Gear reduction reduces stress on your drivetrain
• Dual idler gear configuration adds a 1" offset
• Lighter than the competition

4" Portal Gear Lift Includes:

• (4) Assembled portal hub boxes complete with 9310 gears, seals, output shaft, gaskets, and thrust bearings
• (4) Universal hubs and precision-ground stainless steel slotted rotors with lugs
• (4) Specialized steel alloy backing plates
• (4) Steel caliper mounting plates with spacers
• (2) Steel steering arms
• Extended brake lines with parking brake and brake cable brackets
• All required hardware including recessed castle nut socket

Wheel Requirements:

• 14" or larger wheel required
• Wheels cannot exceed 5" backspacing
• Not compatible with dual beadlock wheels

Fitment:

• Polaris RZR 900 2015-2020
• Polaris RZR 4 900 2015-2018
• Polaris RZR S4 900 2018
• Polaris RZR S 900 2015-2020
• Polaris RZR 900 XC 2015-2017

Notes:

• Without Frame Stiffener & 7-10 Inch Lift Kit
• Manufactured on or after 2015.
• Wheels need to have a center hole of at least 3.25" (82.55mm) or require a 1" wheel spacer.
• This product can impact machine operation. Customer and/or user is responsible for ensuring that this product is compatible with their machine as currently configured, properly installed, and understands any impact this product has or might have on the machine's operation.
